Energy Saving External Rotor Motor With F Insulation Level And Speed Adjust By VFD

  • Energy Saving External Rotor Motor With F Insulation Level And Speed Adjust By VFD
  • Energy Saving External Rotor Motor With F Insulation Level And Speed Adjust By VFD
Place of Origin CHINA
Brand Name HC
Certification ISO9001 CCC CE
Model Number JN-HCP-9
Minimum Order Quantity 50PCS
Price Negotiable
Packaging Details By Sea Pallet /By Air Carton / By Express Packaging
Delivery Time 25 Days
Payment Terms L/C,T/T
Supply Ability 30K PCS/Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Speed Adjust By VFD Cooling Type IC01
Phase Three-phase, Three Phase Rated Speed 750r~3000r
Rated Voltage 380V Or Made To Order. Efficiency Level IE4
Insulation Level F Protection Grade IP54/IP55
Highlight

Energy Saving pm stepper motor

,

External Rotor pm stepper motor

,

VFD interior permanent magnet
Leave a Message
Product Description

Energy-Saving External Rotor Motor with F Insulation Level and Speed Adjust By VFD

Product Description:

Permanent Magnet Synchronous Motor Product Overview
Efficiency at its Best: IE4

The Permanent Magnet Synchronous Motor (PMSM) is a high-performance motor that has been designed to meet the strictest energy efficiency standards. With an Efficiency Level of IE4 , this motor is built to reduce energy consumption and operating costs, making it an environmentally friendly and cost-effective choice.

Powerful and Reliable: Permanent Magnet Rotor

The Permanent Magnet Rotor is the heart of this motor. It is made of high-quality permanent magnets that provide a strong magnetic field, resulting in a powerful and efficient performance. This design also eliminates the need for external excitation, making the motor more reliable and maintenance-free.

External Rotor Motor for Versatility

The Permanent Magnet Synchronous Motor is an External Rotor Motor , meaning that the rotor is located on the outside of the motor. This unique design allows for a more compact and versatile motor, making it suitable for various applications and installation environments.

Quiet Operation: Low Noise

The PMSM is designed to operate at a low noise level, providing a quiet and comfortable working environment. With its advanced technology and precision engineering, this motor produces minimal vibrations and noise, making it ideal for use in noise-sensitive areas.

Energy Saving: VFD Speed Adjust

The Permanent Magnet Synchronous Motor comes equipped with a Variable Frequency Drive (VFD) for speed adjustment. This feature allows for precise control of the motor's speed, resulting in energy savings and improved efficiency. With the ability to adjust the speed from 750 revolutions per minute (r/min) to 3000 r/min , this motor can adapt to various operating conditions and optimize energy usage.

Reliable Performance: Main Parts Imported

To ensure the highest quality and reliability, the main parts of the Permanent Magnet Synchronous Motor are imported from reputable suppliers. This guarantees a consistent and dependable performance, making it a reliable choice for your motor needs.

Experience the Benefits of PMSM

With its high efficiency, low noise, energy-saving capabilities, and reliable performance, the Permanent Magnet Synchronous Motor is the ultimate choice for your motor needs. Its advanced technology, compact design, and versatile operation make it suitable for a wide range of applications, providing exceptional value for your investment.



Features:

  • Product Name: Permanent Magnet Synchronous Motor
  • Speed Adjust: By VFD
  • Phase: Three-phase, Three Phase
  • Working System: S1
  • Insulation level: F
  • Cooling Type: IC01
  • External Rotor Motor
  • Blushless AC Synchronous Motor
  • Permanent Magnet AC Motor


Technical Parameters:

Permanent Magnet Synchronous Motor
Product Type: Blushless AC Synchronous Motor, PMSM, Magnetic Synchronous Motor
Working System: S1
Rate Output: 1.1~11KW
Efficiency Level: IE4
Cooling Type: IC01
Rated Speed: 750r~3000r
Protection Grade: IP54/IP55
Phase: Three-phase, Three Phase
Category: Electric Wrenches
Rated Voltage: 380V Or Made To Order

Motor model Rated power Rated current Rated speed Efficiency Power Factor Stall torque Stall current Pull-out torque Weight
KW 380V/A r/min ŋ% COSØ N.M A N.M kg
HCP90S-2 1.5 2.8 3000 88 ≥0.95 3.1 7 2 23
HCP90L-2 2.2 4 3000 89.7 ≥0.95 3.1 7 2 26.5
HCP100L-2 3 5.4 3000 89.7 ≥0.95 3.1 7.5 2 34
HCP112M-2 4 7.2 3000 90.7 ≥0.95 3.1 7.5 2 41
HCP132S-2 5.5 9.8 3000 92 ≥0.95 3.1 7.5 2 60
HCP132M-2 7.5 13.2 3000 92.5 ≥0.95 3.1 7.5 2 63
HCP160M-2 11 19.3 3000 93.5 ≥0.95 3 7.5 2 109
HCP160L-2 15 26 3000 93.8 ≥0.95 3 7.5 2 119
HCP180M-2 22 38 3000 94.7 ≥0.95 3 7.5 1.8 173
HCP180M-2 30 51.3 3000 95 ≥0.95 3 7.5 1.8 186
HCP180L-2 37 63.8 3000 95.3 ≥0.95 3 7.5 1.8 218
HCP200L-2 30 51.3 3000 95 ≥0.95 3 7.5 1.8 225
HCP200L-2 37 63.5 3000 95.2 ≥0.95 3 7.5 1.8 245
HCP200L-2 45 76.5 3000 95.6 ≥0.95 3 7.5 1.8 265
HCP225S-2 45 76.5 3000 95.6 ≥0.95 3 7.5 1.8 306
HCP225M-2 55 94 3000 95.8 ≥0.95 3 7.5 1.8 340
HCP250M-2 55 94 3000 95.8 ≥0.95 3 7.5 1.8 385
HCP280S-2 75 128 3000 96 ≥0.95 3 7.5 1.8 518
HCP280M-2 90 153.3 3000 96.1 ≥0.95 3 7.5 1.8 550
HCP315S-2 110 187.3 3000 96.2 ≥0.95 2.9 7.1 1.8 932
HCP315M-2 132 225 3000 96.2 ≥0.95 2.9 7.1 1.6 982
HCP315L-2 160 272 3000 96.5 ≥0.95 2.9 7.1 1.6 1100
HCP315L-2 180 306 3000 96.5 ≥0.95 2.9 7.1 1.6 1180
HCP315L-2 200 340 3000 96.6 ≥0.95 2.9 7.1 1.6 1280
HCP355M-2 250 426 3000 96.8 ≥0.95 2.9 7.1 1.6 1720
HCP355L-2 315 533 3000 96.8 ≥0.95 2.9 7.1 1.6 1980



Motor model Rated power Rated current Rated speed Efficiency Power Factor Stall torque Stall current Pull-out torque Weight
KW 380V/A r/min ŋ% COSØ N.M A N.M kg
HCP90S-4 1.1 2.05 1500 88 ≥0.95 3.1 7 2 23
HCP90L-4 1.5 2.78 1500 88.5 ≥0.95 3.1 7 2 27.5
HCP100L-4 2.2 3.98 1500 90.2 ≥0.95 3.1 7.0 2 35
HCP100L-4 3.0 5.4 1500 90.7 ≥0.95 3.1 7.0 2 40
HCP112M-4 4.0 7.2 1500 91 ≥0.95 3.1 7.0 2 45
HCP132S-4 5.5 9.7 1500 92.6 ≥0.95 3.1 7.0 2 63
HCP132M-4 7.5 13.2 1500 93.0 ≥0.95 3 7.0 2 75
HCP160M-4 11.0 19.3 1500 94.0 ≥0.95 3 7.5 2 115
HCP160L-4 15.0 26 1500 94.3 ≥0.95 3 7.5 1.8 135
HCP180M-4 18.5 32 1500 95 ≥0.95 3 7.5 1.8 172
HCP180L-4 22.0 38 1500 95.2 ≥0.95 3 7.5 1.8 185
HCP200L-4 30.0 51.6 1500 95 ≥0.95 3 7.2 1.8 235
HCP225S-4 37.0 63.5 1500 95.8 ≥0.95 3 7.2 1.8 300
HCP225M-4 45.0 77 1500 96.1 ≥0.95 3 7.2 1.8 330
HCP250M-4 55.0 94 1500 96.3 ≥0.95 3 7.2 1.8 410
HCP250M-4 75.0 128 1500 96.5 ≥0.95 3 7.2 1.8 438
HCP280S-4 75.0 128 1500 96.5 ≥0.95 3 7.2 1.8 518
HCP280M-4 90.0 153 1500 97 ≥0.95 3 7.2 1.8 608
HCP280M-4 110.0 187.2 1500 96.7 ≥0.95 3 7.2 1.8 650
HCP280M-4 132.0 223 1500 96.8 ≥0.95 2.9 7.2 1.8 370
HCP315S-4 110.0 187.2 1500 96.7 ≥0.95 2.9 6.9 1.6 935
HCP315L-4 160.0 272 1500 96.8 ≥0.95 2.9 6.9 1.6 1100
HCP315L-4 200.0 340 1500 96.9 ≥0.95 2.9 6.9 1.6 1350
HCP355M-4 250.0 423 1500 97.0 ≥0.95 2.9 6.9 1.6 1900
HCP355L-4 355.0 602 1500 97.1 ≥0.95 2.9 6.9 1.6 2100
HCP355L-4 400.0 678 1500 97.1 ≥0.95 2.9 6.9 1.6 2300



Motor model Rated power Rated current Rated speed Efficiency Power Factor Stall torque Stall current Pull-out torque Weight
KW 380V/A r/min ŋ% COSØ N.M A N.M kg
HCP90S-6 0.75 1.4 1000 87.2 ≥0.95 3.1 5.5 2 24
HCP90L-6 1.1 2.03 1000 88.7 ≥0.95 3.1 5.5 2 26
HCP100L-6 1.5 2.73 1000 89.8 ≥0.95 3.1 6.5 2 35
HCP112M-6 2.2 3.97 1000 91 ≥0.95 3.1 6.5 2 40
HCP132S-6 3 5.37 1000 92 ≥0.95 3.1 6.5 2 60
HCP132M-6 4 7.08 1000 92.8 ≥0.95 3.1 6.5 2 75
HCP132M-6 5.5 9.68 1000 93.5 ≥0.95 3.1 6.5 2 78
HCP160M-6 7.5 13 1000 94.2 ≥0.95 3 6.5 2 110
HCP160L-6 11 19 1000 94.7 ≥0.95 3 6.5 2 135
HCP180L-6 15 25.8 1000 95.1 ≥0.95 3 7 2 175
HCP200L-6 18.5 31.8 1000 95.5 ≥0.95 3 7 1.8 220
HCP200L-6 22 37.8 1000 95.8 ≥0.95 3 7 1.8 230
HCP225M-6 30 51.3 1000 96.2 ≥0.95 2.9 7 1.8 280
HCP250M-6 37 63.2 1000 96.3 ≥0.95 2.9 7 1.8 380
HCP280S-6 45 76.8 1000 96.4 ≥0.95 2.9 7 1.8 480
HCP280M-6 55 93.8 1000 96.5 ≥0.95 2.9 7 1.8 550
HCP315S-6 75 128 1000 96.5 ≥0.95 2.8 6.7 1.6 870
HCP315M-6 90 153 1000 96.5 ≥0.95 2.8 6.7 1.6 950
HCP315L-6 110 187 1000 96.6 ≥0.95 2.8 6.7 1.6 1130
HCP315L-6 132 223 1000 96.6 ≥0.95 2.8 6.7 1.6 1190
HCP355M-6 160 263 1000 96.6 ≥0.95 2.8 6.7 1.6 1720
HCP355M-6 200 340 1000 96.7 ≥0.95 2.8 6.7 1.6 1900
HCP355L-6 250 425 1000 96.7 ≥0.95 2.8 6.7 1.6 2000
HCP355L-6 315 536 1000 96.7 ≥0.95 2.8 6.7 1.6 2200
HCP355L-6 375 637 1000 96.7 ≥0.95 2.8 6.7 1.6 2300
HCP355L-6 400 680 1000 96.7 ≥0.95 2.8 6.7 1.6 2450



Motor model Rated power Rated current Rated speed Efficiency Power Factor Stall torque Stall current Pull-out torque Weight
KW 380V/A r/min ŋ% COSØ N.M A N.M kg
HCP112M-8 1.5 2.74 750 90 ≥0.95 3.1 6 2 43
HCP132S-8 2.2 4 750 90.4 ≥0.95 3.1 6 2 60
HCP132M-8 3 5.3 750 91.5 ≥0.95 3.1 6 2 75
HCP160M-8 4 7.1 750 92.3 ≥0.95 3.1 6 2 102
HCP160M-8 5.5 9.7 750 93.1 ≥0.95 3.1 6 2 110
HCP160L-8 7.5 13.2 750 93.7 ≥0.95 3.1 6 2 131
HCP180M-8 11 19.2 750 94.2 ≥0.95 3 6.6 2 175
HCP200L-8 15 26 750 94.7 ≥0.95 3 6.6 2 235
HCP225S-8 18.5 32 750 95.1 ≥0.95 3 6.6 1.8 280
HCP225M-8 22 38 750 95.4 ≥0.95 3 6.6 1.8 300
HCP250M-8 30 51.5 750 95.6 ≥0.95 2.9 6.6 1.8 380
HCP280S-8 37 63.5 750 95.8 ≥0.95 2.9 6.6 1.8 480
HCP280M-8 45 77 750 95.8 ≥0.95 2.9 6.6 1.8 560
HCP315S-8 55 94.5 750 95.9 ≥0.95 2.8 6.4 1.6 920
HCP315M-8 75 128.5 750 96 ≥0.95 2.8 6.4 1.6 990
HCP315L-8 90 153 750 96 ≥0.95 2.8 6.4 1.6 1083
HCP315L-8 110 188 750 96 ≥0.95 2.8 6.4 1.6 1180
HCP315L-8 132 226 750 96.1 ≥0.95 2.8 6.4 1.6 1250
HCP355M-8 160 275 750 96.1 ≥0.95 2.8 6.4 1.6 1910
HCP355M-8 180 308 750 96.1 ≥0.95 2.8 6.4 1.6 2020
HCP355L-8 200 343 750 96.1 ≥0.95 2.8 6.4 1.6 2080
HCP355L-8 250 428 750 96.1 ≥0.95 2.8 6.4 1.6 2150
HCP355L-8 280 480 750 96.1 ≥0.95 2.8 6.4 1.6 2230
HCP355L-8 315 540 750 96.1 ≥0.95 2.8 6.4 1.6 2300







Energy Saving External Rotor Motor With F Insulation Level And Speed Adjust By VFD 0

Applications:

Permanent Magnet Synchronous Motor - HC
Brand Name: HC
Model Number: JN-HCP-5
Place of Origin: CHINA
Certification: ISO9001 CCC CE
Minimum Order Quantity: 50PCS
Price: Negotiable
Packaging Details: By Sea Pallet /By Air Carton / By Express Packaging
Delivery Time: 25 Days
Payment Terms: L/C,T/T
Supply Ability: 30K PCS/Month
Overview

The Permanent Magnet Synchronous Motor (PMSM) is a type of brushless DC electric motor that is highly efficient and energy-saving. It is also known as Permanent Magnet AC Motor due to its use of permanent magnets in its rotor. This motor is designed and manufactured by HC, a leading company in the field of electric motors.

Applications

The JN-HCP-5 model of Permanent Magnet Synchronous Motor has a wide range of applications in various industries. It is commonly used in electric wrenches, making it an essential tool for professionals in the automotive, construction, and manufacturing industries. It is also used in other power tools, such as drills, saws, and grinders.

Features and Benefits
  • High Efficiency: The PMSM has a higher efficiency compared to other types of motors, resulting in lower energy consumption and cost savings.
  • Energy Saving: Due to its high efficiency, the PMSM helps in reducing energy usage, making it an environmentally-friendly option.
  • Brushless DC Electric Motor: This motor does not have brushes, resulting in less wear and tear and longer lifespan.
  • Permanent Magnet: The use of permanent magnets in the rotor eliminates the need for a separate power source, making it a compact and lightweight motor.
  • Rated Speed: The JN-HCP-5 model has a rated speed range of 750r~3000r, providing flexibility for different applications.
  • Rated Voltage: It has a rated voltage of 380V, but can also be customized according to specific requirements.
  • Category: The PMSM falls under the category of Electric Wrenches, which are essential in various industries for tightening and loosening bolts and nuts.
  • Dimensions: The motor can be customized to meet the specific requirements of customers, making it suitable for different applications.
Conclusion

The Permanent Magnet Synchronous Motor - HC JN-HCP-5 is a reliable and high-quality product that offers numerous benefits and features. Its applications in various industries make it a versatile and essential tool for professionals. With its high efficiency, energy-saving capabilities, and customization options, it is a top choice for those looking for a reliable and efficient motor.



Customization:

Customized Service for HC JN-HCP-5 Permanent Magnet Synchronous Motor
Product Attributes:
  • Brand Name: HC
  • Model Number: JN-HCP-5
  • Place of Origin: CHINA
  • Certification: ISO9001 CCC CE
  • Minimum Order Quantity: 50PCS
  • Price: Negotiable
  • Packaging Details: By Sea Pallet /By Air Carton / By Express Packaging
  • Delivery Time: 25 Days
  • Payment Terms: L/C,T/T
  • Supply Ability: 30K PCS/Month
  • Insulation level: F
  • Cooling Type: IC01
  • Dimensions: As Customers’ Requirements
  • Speed Adjust: By VFD
  • Main Parts: Imported
Key Features of HC Permanent Magnet Synchronous Motor:
  • Synchronous permanent magnet motor with high efficiency and energy saving performance
  • External rotor design for compact size and easy installation
  • Customizable dimensions to meet specific customer requirements
  • Adjustable speed through VFD for flexible operation
  • Imported main parts for reliable and long-lasting performance


Packing and Shipping:

Packaging and Shipping for Permanent Magnet Synchronous Motor

Our Permanent Magnet Synchronous Motor is carefully packaged to ensure safe and secure delivery to our customers. The packaging is designed to protect the motor from any potential damage during transportation and handling.

Packaging:
  • The motor is first wrapped in a layer of protective material, such as foam or bubble wrap.
  • It is then placed in a sturdy cardboard box, with additional padding if needed.
  • The box is sealed with strong tape to prevent any movement during shipping.
Shipping:

We offer a variety of shipping options to meet our customers' needs. These include:

  • Standard shipping: Our motor is shipped via a reliable carrier, such as UPS or FedEx, and is estimated to arrive within 3-5 business days after leaving our warehouse.
  • Expedited shipping: For urgent orders, we offer expedited shipping through a priority carrier, with estimated delivery within 1-2 business days.
  • International shipping: We ship our motors worldwide, with various shipping options available to meet different international shipping requirements.

Our team carefully monitors the shipping process to ensure timely delivery and will provide tracking information to our customers once their order has been shipped. We also offer insurance options for added protection during shipping.



FAQ:

  • Q: What is the brand name of this product?
  • A: The brand name of this product is HC.
  • Q: What is the model number of this product?
  • A: The model number of this product is JN-HCP-5.
  • Q: Where is this product manufactured?
  • A: This product is manufactured in China.
  • Q: What certifications does this product have?
  • A: This product is certified with ISO9001, CCC, and CE.
  • Q: What is the minimum order quantity for this product?
  • A: The minimum order quantity for this product is 50PCS.
  • Q: What is the price of this product?
  • A: The price of this product is negotiable.
  • Q: How is this product packaged for shipping?
  • A: This product is packaged either by sea pallet, air carton, or express packaging.
  • Q: How long is the delivery time for this product?
  • A: The delivery time for this product is 25 days.
  • Q: What are the accepted payment terms for this product?
  • A: The accepted payment terms for this product are L/C and T/T.
  • Q: What is the supply ability for this product?
  • A: The supply ability for this product is 30K PCS per month.
Tags:

VFD Permanent Magnet Synchronous Motor

380V Permanent Magnet Synchronous Motor

IE4 Permanent Magnet Synchronous Motor
