Alnico Magnet Manufacturing Process Casting Or Sintering Grade Alnico 5
| Place of Origin | CHINA |
|---|---|
| Brand Name | JN |
| Certification | ISO9001 |
| Model Number | JN-AL-7 |
| Minimum Order Quantity | 1000PCS |
| Price | Negotiable |
| Packaging Details | By Sea Pallet /By Air Carton / By Express Packaging |
| Delivery Time | 25 Days |
| Payment Terms | L/C,T/T |
| Supply Ability | 2000K PCS/Month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Bar, Disc, Ring, Block, Cylinder | Applications | Sensors, Motors, Generators, Loudspeakers, Magnetic Separators, Etc. |
|---|---|---|---|
| Grade | Alnico 2, Alnico 5, Alnico 8 | Maximum Working Temperature | 450-550°C |
| Manufacturing Process | Casting Or Sintering | Density | 7.3-7.5 G/cm3 |
| Composite | AlNiCo Magnet | Max Working Temperature | 550Degree C |
| Highlight | Casting alnico 5,Sintering alnico 5 pickup magnets,Motors alnico v |
||
Product Description
Alnico Magnet Manufacturing Process Casting Or Sintering Grade Alnico 5
Product Description:
Alnico Magnet Product Overview
The Alnico Magnet is a type of permanent magnet made from an aluminum-nickel-cobalt (AlNiCo) alloy. It is known for its high temperature resistance and strong magnetic properties. Alnico magnets are commonly used in various industries, including electronics, automotive, and aerospace, due to their durability and reliability.
Product Attributes
Tolerance: ±0.05mm
Grade: Alnico 2, Alnico 5, Alnico 8
Composite: AlNiCo Magnet
Maximum Working Temperature: 450-550°C
Magnetic Properties: High Coercivity, High Remanence, High Energy Product
High Temperature Alnico Magnets
One of the main advantages of the Alnico Magnet is its ability to withstand high temperatures. With a maximum working temperature of 450-550°C, these magnets can be used in applications that require high heat resistance, such as in motors, generators, and turbines.
Aluminum Nickel Cobalt Magnets
The Alnico Magnet is made from an AlNiCo alloy, which is a combination of aluminum, nickel, and cobalt. This unique composition gives the magnet its strong magnetic properties and high temperature resistance. These magnets are also known for their corrosion resistance, making them suitable for use in harsh environments.
Durable Alnico Magnetic Material
The Alnico Magnet is a highly durable magnetic material that can withstand extreme conditions without losing its magnetic properties. It is resistant to demagnetization and can maintain its strength even in high temperature and high vibration environments. This makes it a popular choice for use in industrial and commercial applications.
In conclusion, the Alnico Magnet is a versatile and reliable product with high temperature resistance, strong magnetic properties, and durability. Its various grades and composite make it suitable for a wide range of applications, making it a valuable asset in many industries.
Features:
- Product Name: Alnico Magnet
- Density: 7.3-7.5 G/cm3
- Maximum Working Temperature: 450-550°C
- Manufacturing Process: Casting Or Sintering
- Material: Alnico
- Magnetic Properties:
- High Coercivity
- High Remanence
- High Energy Product
- Magnetic Alloys of Aluminum-Nickel-Cobalt
- High Temperature Alnico Magnets
- Aluminum Nickel Cobalt Magnets
Technical Parameters:
| Parameter | Value |
|---|---|
| Shape | Bar, Disc, Ring, Block, Cylinder |
| Manufacturing Process | Casting or Sintering |
| Density | 7.3-7.5 g/cm 3 |
| Max Working Temperature | 550°C |
| Grade | Alnico 2, Alnico 5, Alnico 8 |
| Magnetic Properties | High Coercivity, High Remanence, High Energy Product |
| Maximum Working Temperature | 450-550°C |
| Composite | AlNiCo Magnet |
| Applications | Sensors, Motors, Generators, Loudspeakers, Magnetic Separators, etc. |
| Material | Alnico |
| Key Features | Description |
|---|---|
| Powerful Alnico Magnets | Utilizes Alnico material to produce strong magnetic fields |
| High Temperature Alnico Magnets | Capable of maintaining magnetic properties at temperatures up to 550°C |
| Powerful Alnico Magnets China | Manufactured in China with high quality Alnico material |
| Alnico Disc Magnet | Disc-shaped Alnico magnet with high magnetic strength |
| Alnico Block Magnet | Rectangular-shaped Alnico magnet with strong magnetic force |
| Grade | MMPA | Residual Induction | Coercive Force | Max. Energy Product | Max. Working Temperature |
||
| Br | Hcb | (BH)max | Tw | ||||
| kGs | T | kOe | KA/M | MGOe KJ/m³ | ℃ | ||
| LNl0 | ALNICO3 | 6.0 | 0.60 | 0.50 | 40 | 1.25 10 | 550 |
| LNG 10 | 6.0 | 0.60 | 0.55 | 44 | 1.25 10 | 550 | |
| LNG12 | ALNICO2 | 7.0 | 0.70 | 0.55 | 44 | 1.50 12 | 550 |
| LNG 13 | 6.8 | 0.68 | 0.60 | 48 | 1.63 13 | 550 | |
| LNG16 | ALNICO4 | 8.0 | 0.80 | 0.60 | 48 | 2.00 16 | 550 |
| LNG18 | 9.0 | 0.90 | 0.60 | 48 | 2.25 18 | 550 | |
| LNG37 | ALNICOS | 12.0 | 1.20 | 0.60 | 48 | 4.63 37 | 550 |
| LNG40 | 12.3 | 1.23 | 0.60 | 48 | 5.00 40 | 550 | |
| LNG44 | 12.5 | 1.25 | 0.65 | 52 | 5.50 44 | 550 | |
| LNG48 | ALNICOSDG | 12.8 | 1.28 | 0.70 | 56 | 6.00 48 | 550 |
| LNG52 | 13.0 | 1.30 | 0.70 | 56 | 6.50 52 | 550 | |
| LNG56 | ALNICO5—7 | 13.0 | 1.30 | 0.72 | 58 | 7.00 56 | 550 |
| LNG60 | 13.3 | 1.33 | 0.75 | 60 | 7.50 60 | 550 | |
| LNGT28 | ALNICO6 | 10.0 | 1.00 | 0.70 | 56 | 3.50 28 | 550 |
| LNGT30 | 11.0 | 1.10 | 0.70 | 56 | 3.75 30 | 550 | |
| LNGT18 | ALNICO8 | 5.8 | 0.58 | 1.00 | 80 | 2.25 18 | 550 |
| LNGT32 | 8.0 | 0.80 | 1.zs | 100 | 4.00 32 | 550 | |
| LNGT38 | 8.0 | 0.80 | 1.38 | 110 | 4.75 38 | 550 | |
| LNGT44 | 8.5 | 0.85 | 1.45 | lls | 5.50 44 | 550 | |
| LNGT48 | ALNICO8HE | 9.0 | 0.90 | 1.50 | 120 | 6.00 48 | 550 |
| LNGT60 | ALNICO9 | 9.0 | 0.90 | 1.38 | 110 | 7.50 60 | 550 |
| LNGT72 | 10.5 | 1.05 | 1.40 | 112 | 9.00 72 | 550 | |
| LNGT80 | 10.8 | 1.08 | 1.50 | 120 | 10.00 80 | 550 | |
| LNGT88 | 11.0 | 1.10 | 1.45 | 115 | 11.00 88 | 550 | |
| LNGT96 | 11.5 | 1.15 | 1.48 | 118 | 12.00 96 | 550 | |
| LNGT36J | ALNICO8HC | 7.0 | 0.70 | 1.75 | 140 | 4.50 36 | 550 |
| LNGT40J | 7.0 | 0.70 | 1.75 | 140 | 5.00 40 | 550 | |
| LNGT44J | 7.5 | 0.75 | 1.75 | 140 | 5.50 44 | 550 | |
| LNGT48J | 8.0 | 0.80 | 1.82 | 145 | 6.00 48 | 550 | |
| LNGT52J | 8.5 | 0.85 | 1.75 | 140 | 6.50 52 | 550 | |
| Grade | MMPA | Residual Induction | Coercive Force | Max. Energy Product | Max. Working Temperature |
||
| Br | Hcb | (BH)max | Tw | ||||
| kGs | T | kOe | KA/M | MGOe KJ/m³ | ℃ | ||
| FLN8 | S.ALNICO3 | 5.0 | 0.50 | 0.50 | 40 | 1.00 8 | 450 |
| FLNG12 | S.ALNICO2 | 6.5 | 0.65 | 0.60 | 48 | 1.50 12 | 450 |
| FLNGT18 | S.ALNICO7 | 6.0 | 0.60 | 1.13 | 90 | 2.20 18 | 450 |
| FLNG34 | S.ALNICO5 | 12.0 | 1.20 | 0.60 | 48 | 4.25 34 | 450 |
| FLNGT28 | S.ALNICO6 | 10.5 | 1.05 | 0.70 | 56 | 3.50 28 | 450 |
| FLNGT38 | S.ALNICO8 | 8.0 | 0.80 | 1.50 | 120 | 4.75 38 | 450 |
| FLNGT42 | S.ALNICO8 | 8.8 | 0.88 | 1.50 | 120 | 5.25 42 | 450 |
| FLNGT33J | S.ALNICO8HC | 7.0 | 0.70 | 1.75 | 140 | 4.13 33 | 450 |
Applications:
Alnico Magnet - Powerful Magnets for Industrial Applications
Brand Name: JN
Model Number: JN-AL-3
Place of Origin: CHINA
Certification: ISO9001
Minimum Order Quantity: 1000PCS
Price: Negotiable
Packaging Details: By Sea Pallet /By Air Carton / By Express Packaging
Delivery Time: 25 Days
Payment Terms: L/C,T/T
Supply Ability: 2000K PCS/Month
Composite: AlNiCo Magnet
Maximum Working Temperature: 450-550°C
Grade: Alnico 2, Alnico 5, Alnico 8
Max Working Temperature: 550Degree C
What is Alnico Magnet?
Alnico magnet is a type of permanent magnet made from an alloy of aluminum, nickel, and cobalt, with small amounts of other elements such as iron, copper, and titanium. It is known for its strong magnetic field and high resistance to demagnetization, making it ideal for various industrial applications.
Applications of Alnico Magnets
With its strong magnetic properties, Alnico magnets are widely used in various industries for different purposes. Some of the common applications of Alnico magnets include:
- Sensors: Alnico magnets are used in sensors to detect and measure magnetic fields. They are commonly used in compasses, magnetic speed and direction sensors, and proximity sensors.
- Electric Motors: Alnico magnets are used in electric motors to create motion by converting electrical energy into mechanical energy. They are commonly used in small motors for household appliances, as well as in larger motors for industrial applications.
- Generators: Alnico magnets are used in generators to convert mechanical energy into electrical energy. They are commonly used in power plants, wind turbines, and hydroelectric dams.
- Loudspeakers: Alnico magnets are used in loudspeakers to produce sound by converting electrical energy into mechanical energy. They are known for their ability to produce high-quality sound with minimal distortion.
- Magnetic Separators: Alnico magnets are used in magnetic separators to separate and remove magnetic materials from non-magnetic materials. They are commonly used in recycling facilities, mining operations, and food processing plants.
- And many more: Alnico magnets are also used in various other applications such as guitar pickups, holding magnets, and magnetic chucks.
Why Choose Alnico Magnets?
Alnico magnets are known for their powerful magnetic field, high resistance to demagnetization, and ability to withstand high temperatures. These properties make them ideal for industrial applications where strong and reliable magnets are required.
Industrial Alnico Magnets from JN
JN is a leading manufacturer of Alnico magnets in China. Our Alnico magnets are made with high-quality materials and advanced manufacturing techniques, ensuring strong and reliable performance in various industrial applications. We offer a wide range of Alnico magnet grades, including Alnico 2, Alnico 5, and Alnico 8, to meet different application requirements. Our magnets also have a maximum working temperature of 550°C, making them suitable for use in high-temperature environments.
Strong Alnico Magnets for Your Business
If you are looking for powerful and reliable Alnico magnets for your business, look no further than JN. Our Alnico magnets are available in various shapes and sizes, and we can also customize them according to your specific needs. With our competitive prices, prompt delivery, and excellent customer service, we are confident that we can meet all your Alnico magnet needs. Contact us today to learn more about our products and services.
Customization:
Alnico Magnet Customization Service
Brand Name: JN
Model Number: JN-AL-3
Place of Origin: CHINA
Certification: ISO9001
Minimum Order Quantity: 1000PCS
Price: Negotiable
Packaging Details: By Sea Pallet /By Air Carton / By Express Packaging
Delivery Time: 25 Days
Payment Terms: L/C,T/T
Supply Ability: 2000K PCS/Month
Tolerance: ±0.05mm
Density: 7.3-7.5 G/cm3
Grade: Alnico 2, Alnico 5, Alnico 8
Manufacturing Process: Casting Or Sintering
Shape: Bar, Disc, Ring, Block, Cylinder
At JN, we specialize in providing durable Alnico magnetic material customization services. Our Alnico alloy magnets are made with the highest quality materials, ensuring long-lasting performance and reliability. We offer customized sizes and shapes to meet the specific needs of our customers.
With our precise tolerance of ±0.05mm, we guarantee the highest level of accuracy in our customization process. Our wide range of grades, including Alnico 2, Alnico 5, and Alnico 8, allows our customers to choose the best option for their specific applications.
We also offer various manufacturing processes such as casting or sintering to cater to different requirements. Our shapes include bar, disc, ring, block, and cylinder, providing our customers with a wide selection to choose from.
Trust JN for all your Alnico magnet customization needs. Contact us now to learn more about our services and how we can help you achieve your desired results.
Packing and Shipping:
Packaging and Shipping
Alnico Magnet will be carefully packaged to ensure safe transportation and delivery to our customers. Each magnet will be individually wrapped and placed in a sturdy cardboard box with cushioning materials to prevent any damage during shipping.
The packaging will also include a label with the product name, size, and quantity for easy identification. Additionally, the boxes will be sealed with tamper-proof tape to ensure the integrity of the product.
For shipping, we offer various options to meet our customers' needs. We can arrange for local pickup, ground shipping, or expedited delivery via air. Our team will work with our customers to determine the most efficient and cost-effective method of shipping based on their location and timeline.
We take great care in our packaging and shipping processes to ensure that our customers receive their Alnico Magnets in perfect condition. However, in the unlikely event of any damage during shipping, we have a hassle-free return and exchange policy to ensure customer satisfaction.
FAQ:
- Q: What is the brand name of this product?
- A: The brand name of this product is JN.
- Q: What is the model number of this product?
- A: The model number of this product is JN-AL-3.
- Q: Where is this product manufactured?
- A: This product is manufactured in China.
- Q: Does this product have any certification?
- A: Yes, this product has ISO9001 certification.
- Q: What is the minimum order quantity for this product?
- A: The minimum order quantity for this product is 1000PCS.
- Q: Is the price of this product negotiable?
- A: Yes, the price of this product is negotiable.
- Q: How is this product packaged for shipping?
- A: This product can be packaged in three different ways: By Sea Pallet, By Air Carton, or By Express Packaging.
- Q: How long will it take for this product to be delivered?
- A: The delivery time for this product is 25 days.
- Q: What are the accepted payment terms for this product?
- A: The accepted payment terms for this product are L/C and T/T.
- Q: What is the supply ability for this product?
- A: The supply ability for this product is 2000K PCS per month.
