Alnico Magnets For Cylindrical Perforation Logistics Electronic Lock Hysteresis Motor

Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xMagnetic Properties | High Coercivity, High Remanence, High Energy Product | Max Working Temperature | 550Degree C |
---|---|---|---|
Composite | AlNiCo Magnet | Material | Alnico |
Applications | Sensors, Motors, Generators, Loudspeakers, Magnetic Separators, Etc. | Maximum Working Temperature | 450-550°C |
Shape | Bar, Disc, Ring, Block, Cylinder | Tolerance | ±0.05mm |
Highlight | cylindrical magnet alnico,logistics magnet alnico,electronic earth metal magnets |
Alnico Magnets for cylindrical perforation logistics electronic lock hysteresis motor
Product Description:
Alnico Magnet is a type of permanent magnet made from a composite of aluminum, nickel, and cobalt, with small amounts of other elements such as iron, copper, and titanium. It is a cost-effective magnet with high magnetic properties, making it a popular choice in various industries.
Alnico Magnet is made from a composite of aluminum, nickel, and cobalt, along with small amounts of other elements. This unique composition gives it its strong magnetic properties, making it a reliable and durable magnet for industrial use.
Alnico Magnet is precisely machined with a tolerance of ±0.05mm, ensuring its accuracy and consistency in performance. This makes it suitable for applications that require high precision and reliability.
Alnico Magnet is available in a wide range of shapes and sizes, including bar, disc, ring, block, and cylinder. This allows for flexibility in design and application, making it suitable for various industrial needs.
As the name suggests, Alnico Magnet is made from Alnico, a type of permanent magnetic material that is highly resistant to demagnetization. This makes it a long-lasting and reliable magnet for industrial use.
Alnico Magnet is known for its high coercivity, which means it can resist demagnetization, making it a stable and long-lasting magnet. It also has high remanence, which means it can retain its magnetism even after being removed from a magnetic field. Additionally, it has a high energy product, which refers to its ability to produce a strong magnetic field.
Alnico Magnet is a permanent magnet, which means it can maintain its magnetic properties for a long time without the need for an external magnetic field. This makes it a cost-effective option for industrial applications as it does not require frequent replacements.
Alnico Magnet is a cost-effective option for industrial applications, offering high magnetic properties at a reasonable price. This makes it a popular choice for various industries, including automotive, aerospace, and electronics.
Alnico Magnet is precisely machined to meet specific requirements and tolerances, ensuring its accuracy and consistency. This makes it suitable for applications that require high precision and reliability, such as electric motors and generators.
Alnico Magnet is known for its high temperature stability, which means it can maintain its magnetic properties even at high temperatures. This makes it suitable for use in applications that involve high temperatures, such as in engines and industrial machinery.
Alnico Magnet is available in a wide range of shapes and sizes, making it suitable for various industrial applications. This allows for flexibility in design and usage, making it a versatile option for different industries.
Alnico Magnet is widely used in various industrial applications, including electric motors, generators, sensors, loudspeakers, and more. Its high magnetic properties, cost-effectiveness, and reliability make it a popular choice in industries such as automotive, aerospace, and electronics.
In conclusion, Alnico Magnet is a high-performance permanent magnet with a wide range of industrial applications. Its unique composition, high magnetic properties, and precision machining make it a reliable and cost-effective option for various industries.
Features:
- Durable Alnico Magnetic Material
- Cost-effective Alnico Magnets
- Strong Alnico Magnets
- Wide Range of Applications
- High Temperature Resistance
- Product Name: Alnico Magnet
- Maximum Working Temperature: 450-550°C
- Magnetic Properties: High Coercivity, High Remanence, High Energy Product
- Material: Alnico
- Applications: Sensors, Motors, Generators, Loudspeakers, Magnetic Separators, Etc.
- Density: 7.3-7.5 G/cm3
Technical Parameters:
Technical Parameters | Description |
---|---|
Shape | Bar, Disc, Ring, Block, Cylinder |
Magnetic Properties | High Coercivity, High Remanence, High Energy Product |
Maximum Working Temperature | 450-550°C |
Density | 7.3-7.5 G/cm3 |
Material | Alnico |
Applications | Sensors, Motors, Generators, Loudspeakers, Magnetic Separators, Etc. |
Grade | Alnico 2, Alnico 5, Alnico 8 |
Manufacturing Process | Casting Or Sintering |
Tolerance | ±0.05mm |
Composite | AlNiCo Magnet |
Key Features | Aluminum Nickel Cobalt Magnets, Powerful Alnico Magnets |
Grade | MMPA | Residual Induction | Coercive Force | Max. Energy Product | Max. Working Temperature |
||
Br | Hcb | (BH)max | Tw | ||||
kGs | T | kOe | KA/M | MGOe KJ/m³ | ℃ | ||
LNl0 | ALNICO3 | 6.0 | 0.60 | 0.50 | 40 | 1.25 10 | 550 |
LNG 10 | 6.0 | 0.60 | 0.55 | 44 | 1.25 10 | 550 | |
LNG12 | ALNICO2 | 7.0 | 0.70 | 0.55 | 44 | 1.50 12 | 550 |
LNG 13 | 6.8 | 0.68 | 0.60 | 48 | 1.63 13 | 550 | |
LNG16 | ALNICO4 | 8.0 | 0.80 | 0.60 | 48 | 2.00 16 | 550 |
LNG18 | 9.0 | 0.90 | 0.60 | 48 | 2.25 18 | 550 | |
LNG37 | ALNICOS | 12.0 | 1.20 | 0.60 | 48 | 4.63 37 | 550 |
LNG40 | 12.3 | 1.23 | 0.60 | 48 | 5.00 40 | 550 | |
LNG44 | 12.5 | 1.25 | 0.65 | 52 | 5.50 44 | 550 | |
LNG48 | ALNICOSDG | 12.8 | 1.28 | 0.70 | 56 | 6.00 48 | 550 |
LNG52 | 13.0 | 1.30 | 0.70 | 56 | 6.50 52 | 550 | |
LNG56 | ALNICO5—7 | 13.0 | 1.30 | 0.72 | 58 | 7.00 56 | 550 |
LNG60 | 13.3 | 1.33 | 0.75 | 60 | 7.50 60 | 550 | |
LNGT28 | ALNICO6 | 10.0 | 1.00 | 0.70 | 56 | 3.50 28 | 550 |
LNGT30 | 11.0 | 1.10 | 0.70 | 56 | 3.75 30 | 550 | |
LNGT18 | ALNICO8 | 5.8 | 0.58 | 1.00 | 80 | 2.25 18 | 550 |
LNGT32 | 8.0 | 0.80 | 1.zs | 100 | 4.00 32 | 550 | |
LNGT38 | 8.0 | 0.80 | 1.38 | 110 | 4.75 38 | 550 | |
LNGT44 | 8.5 | 0.85 | 1.45 | lls | 5.50 44 | 550 | |
LNGT48 | ALNICO8HE | 9.0 | 0.90 | 1.50 | 120 | 6.00 48 | 550 |
LNGT60 | ALNICO9 | 9.0 | 0.90 | 1.38 | 110 | 7.50 60 | 550 |
LNGT72 | 10.5 | 1.05 | 1.40 | 112 | 9.00 72 | 550 | |
LNGT80 | 10.8 | 1.08 | 1.50 | 120 | 10.00 80 | 550 | |
LNGT88 | 11.0 | 1.10 | 1.45 | 115 | 11.00 88 | 550 | |
LNGT96 | 11.5 | 1.15 | 1.48 | 118 | 12.00 96 | 550 | |
LNGT36J | ALNICO8HC | 7.0 | 0.70 | 1.75 | 140 | 4.50 36 | 550 |
LNGT40J | 7.0 | 0.70 | 1.75 | 140 | 5.00 40 | 550 | |
LNGT44J | 7.5 | 0.75 | 1.75 | 140 | 5.50 44 | 550 | |
LNGT48J | 8.0 | 0.80 | 1.82 | 145 | 6.00 48 | 550 | |
LNGT52J | 8.5 | 0.85 | 1.75 | 140 | 6.50 52 | 550 |
Grade | MMPA | Residual Induction | Coercive Force | Max. Energy Product | Max. Working Temperature |
||
Br | Hcb | (BH)max | Tw | ||||
kGs | T | kOe | KA/M | MGOe KJ/m³ | ℃ | ||
FLN8 | S.ALNICO3 | 5.0 | 0.50 | 0.50 | 40 | 1.00 8 | 450 |
FLNG12 | S.ALNICO2 | 6.5 | 0.65 | 0.60 | 48 | 1.50 12 | 450 |
FLNGT18 | S.ALNICO7 | 6.0 | 0.60 | 1.13 | 90 | 2.20 18 | 450 |
FLNG34 | S.ALNICO5 | 12.0 | 1.20 | 0.60 | 48 | 4.25 34 | 450 |
FLNGT28 | S.ALNICO6 | 10.5 | 1.05 | 0.70 | 56 | 3.50 28 | 450 |
FLNGT38 | S.ALNICO8 | 8.0 | 0.80 | 1.50 | 120 | 4.75 38 | 450 |
FLNGT42 | S.ALNICO8 | 8.8 | 0.88 | 1.50 | 120 | 5.25 42 | 450 |
FLNGT33J | S.ALNICO8HC | 7.0 | 0.70 | 1.75 | 140 | 4.13 33 | 450 |
Applications:
Brand Name: JN
Model Number: JN-AL-3
Place of Origin: CHINA
Certification: ISO9001
Minimum Order Quantity: 1000PCS
Price: Negotiable
Packaging Details: By Sea Pallet /By Air Carton / By Express Packaging
Delivery Time: 25 Days
Payment Terms: L/C,T/T
Supply Ability: 2000K PCS/Month
Maximum Working Temperature: 450-550°C
Grade: Alnico 2, Alnico 5, Alnico 8
Manufacturing Process: Casting Or Sintering
Tolerance: ±0.05mm
Composite: AlNiCo Magnet
Alnico Magnet, also known as Aluminum Nickel Cobalt Magnets, is a type of permanent magnet made from a composite of aluminum, nickel, and cobalt, along with iron and other elements. It is one of the earliest permanent magnetic materials invented, and it has been widely used in various industries due to its strong magnetic properties and high temperature resistance.
- High temperature resistance: Alnico magnets can maintain their magnetic properties at temperatures up to 450-550°C, making them suitable for use in high-temperature environments.
- Strong magnetic properties: Alnico magnets have a high magnetic flux density, making them one of the strongest permanent magnets available.
- Wide range of applications: Alnico magnets are widely used in industrial, automotive, aerospace, electrical, mechanical, medical, education, and renewable energy industries.
- Durable and long-lasting: Alnico magnets have a long service life and do not easily demagnetize or corrode.
Alnico magnets have a wide range of applications due to their unique properties. Some of the common applications include:
- Industrial: Alnico magnets are used in various industrial applications, such as magnetic separators, holding and lifting systems, motors, generators, and sensors.
- Automotive: Alnico magnets are used in electric motors, sensors, and switches in the automotive industry.
- Aerospace: Alnico magnets are used in various aerospace applications, such as navigation systems, gyroscopes, and electronic controls.
- Electrical: Alnico magnets are used in electrical applications, such as relays, switches, and meters.
- Mechanical: Alnico magnets are used in mechanical applications, such as clamps, chucks, and couplings.
- Medical: Alnico magnets are used in medical equipment, such as MRI machines, pacemakers, and dental tools.
- Education: Alnico magnets are used in educational demonstrations and experiments, such as magnetic levitation and motors.
- Renewable energy: Alnico magnets are used in wind turbines and generators for renewable energy production.
Alnico Magnet is a versatile and reliable product that offers high temperature resistance, strong magnetic properties, and a wide range of applications in various industries. With its durable and long-lasting features, it has become an essential component in many industrial and technological advancements. Choose Alnico Magnet from JN and experience its exceptional performance and quality.
Customization:
Brand Name: JN
Model Number: JN-AL-3
Place of Origin: CHINA
Certification: ISO9001
Minimum Order Quantity: 1000PCS
Price: Negotiable
Packaging Details: By Sea Pallet /By Air Carton / By Express Packaging
Delivery Time: 25 Days
Payment Terms: L/C,T/T
Supply Ability: 2000K PCS/Month
Maximum Working Temperature: 450-550°C
Shape: Bar, Disc, Ring, Block, Cylinder
Applications: Sensors, Motors, Generators, Loudspeakers, Magnetic Separators, Etc.
Manufacturing Process: Casting Or Sintering
Material: Alnico
- Durable Alnico Magnetic Material
- Industrial Alnico Magnets
- Cost-effective Alnico Magnets
- Customized Solutions to Meet Your Specific Needs
FAQ:
- Q: What is the brand name of this product?
- A: The brand name of this product is JN.
- Q: What is the model number of this product?
- A: The model number of this product is JN-AL-3.
- Q: Where is this product manufactured?
- A: This product is manufactured in China.
- Q: Is this product certified?
- A: Yes, this product is certified with ISO9001.
- Q: What is the minimum order quantity for this product?
- A: The minimum order quantity for this product is 1000PCS.
- Q: Can the price of this product be negotiated?
- A: Yes, the price of this product is negotiable.
- Q: How is this product packaged for shipping?
- A: This product is packaged and shipped using either sea pallet, air carton, or express packaging.
- Q: What is the estimated delivery time for this product?
- A: The estimated delivery time for this product is 25 days.
- Q: What are the accepted payment terms for this product?
- A: The accepted payment terms for this product are L/C and T/T.
- Q: What is the supply ability of this product?
- A: The supply ability of this product is 2000K PCS per month.
