Industrial Super Strong Magnet with Working Temp 80-230 Centigrade and Custom Options

  • Industrial Super Strong Magnet with Working Temp 80-230 Centigrade and Custom Options
  • Industrial Super Strong Magnet with Working Temp 80-230 Centigrade and Custom Options
  • Industrial Super Strong Magnet with Working Temp 80-230 Centigrade and Custom Options
  • Industrial Super Strong Magnet with Working Temp 80-230 Centigrade and Custom Options
Place of Origin CHINA
Brand Name JN
Certification ISO9001
Model Number JN-ND-10
Minimum Order Quantity 1000PCS
Price Negotiable
Packaging Details By Sea Pallet /By Air Carton / By Express Packaging
Delivery Time 21 Days
Payment Terms L/C,T/T
Supply Ability 1 000K PCS/Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Working Temp 80-230 Centigrade Coating Nickel
Size Custom Application Motor
Shape Step Grand Available N35-N52
Process Sintering Raw Material NdFeB Rare Earth Materials
Category Neodymium Magnets
Highlight

industrial ndfeb magnet

,

industrial ndfeb magnets

,

custom ndfeb magnet
Leave a Message
Product Description

Industrial Super Strong Magnet with Working Temp 80-230 Centigrade and Custom Options

Product Description:



NdFeB magnets have a very tight tolerance level, with a standard tolerance of +/- 0.05 mm. This means that the dimensions of the magnet will be very precise and consistent, ensuring its proper fit and function in any application.

Key Features:
  • Powerful Magnet: NdFeB magnets are known for their exceptional strength and magnetic properties, making them the most powerful type of magnet available.
  • High Energy Density: Due to the combination of neodymium, iron, and boron, NdFeB magnets have a high energy density, meaning they can store a large amount of magnetic energy.
  • Strong Magnetic Material: NdFeB magnets have a high coercivity, which makes them very difficult to demagnetize, ensuring their long-lasting magnetic strength.
  • Corrosion Resistance: NdFeB magnets are coated with a protective layer to prevent corrosion and ensure their durability in various environments.

NdFeB Magnet is the ultimate solution for high-performance magnets. With its powerful magnetic strength, high energy density, and strong magnetic properties, it is the preferred choice for a wide range of applications in industries such as electronics, automotive, and medical. With customization options and precise tolerance levels, NdFeB magnets offer a reliable and efficient solution for any magnetic needs.

Technical Parameters:

NdFeB Permanent Magnet Neodymium Rare Earth Magnet
Working Temperature 80-230 Centigrade
Application Traction Motor, Automotive EPS Motor, Air Conditioner
Process Sintering
Grade Available N35-N52
Coating Nickel, Epoxy, Zn, Ni
Raw Material NdFeB Rare Earth Materials
Size Custom
Max Working Temperature 230ºC
Tolerance +/- 0.05 mm
Type of Magnet NdFeB Magnets

Application

NdFeB Magnet is used in many different applications, including:

  • Electric motors and generators: NdFeB Magnet is used in the rotors of electric motors and generators to convert electrical energy into mechanical energy. Its high magnetic energy product and high coercivity make it ideal for these applications.
  • Computer hard drives: NdFeB Magnet is used in computer hard drives to store data. Its high resistance to demagnetization ensures that the data is not lost even when the computer is turned off.
  • Magnetic separators: NdFeB Magnet is used in magnetic separators to separate ferrous materials from non-ferrous materials. Its strong magnetic properties make it effective in removing unwanted metals from different materials.
  • Sensors: NdFeB Magnet is used in sensors to detect magnetic fields. Its high sensitivity and strong magnetic properties make it ideal for this application.
  • Medical equipment: NdFeB Magnet is used in medical equipment such as MRI machines and magnetic resonance imaging. Its high temperature resistance makes it suitable for use in medical applications.
  • Speakers and headphones: NdFeB Magnet is used in speakers and headphones to convert electrical signals into sound. Its strong magnetic properties help in producing high-quality sound.
Scene

Imagine a manufacturing plant producing electric motors for cars. The engineers are using NdFeB Magnets to create the rotors of the motors. They carefully place the magnets in a specific order to ensure maximum efficiency and power. The magnets are then coated with nickel epoxy to protect them from corrosion. Once the motors are assembled, they are put through a series of tests to ensure they meet the high-quality standards set by the company. The motors are then shipped to the car manufacturing plant, where they are installed in the cars. The use of NdFeB Magnets in the motors ensures that the cars have a powerful and efficient engine, providing a smoother and more reliable driving experience for the customers.

Conclusion

NdFeB Magnet, also known as Neodymium Permanent Magnet, is a powerful permanent magnet that has a wide range of applications due to its strong magnetic properties. Its high magnetic energy product, high coercivity, and high temperature resistance make it ideal for use in various industries. With the JN brand, customers can be assured of high-quality NdFeB Magnets that are made from top-quality raw materials and manufactured with precision. Choose JN-ND-10 for your next project and experience the power of NdFeB Magnet.



Magnetic Properties
Grade Remanence Intrinsic Coercivity Max Magnetic Energy Product Temperature Coefficient Max Working Temperture Density
Br Hcj (BH)max α Br β Hcj Tw ρ
T kGs kA/m kOe KJ/m3 MGOe %/℃ %/℃ ℃ g/cm3
N55 ≥1.45 ≥14.5 ≥955 ≥12 406-437 51-55 -0.12 -0.8 80 ≥7.5
N54 ≥1.44 ≥14.4 ≥955 ≥12 398-437 50-55 -0.12 -0.8 80 ≥7.5
N52 1.42-1.44 14.2-14.4 ≥955 ≥12 390-422 49-53 -0.12 -0.8 80 ≥7.5
N50 1.4-1.42 14-14.2 ≥955 ≥12 374-406 47-51 -0.12 -0.8 80 ≥7.5
N48 1.37-1.4 13.7-14 ≥955 ≥12 366-390 46-49 -0.12 -0.8 80 ≥7.5
N45 1.32-1.37 13.2-13.7 ≥955 ≥12 342-366 43-46 -0.12 -0.8 80 ≥7.5
54M ≥1.44 ≥14.4 ≥1114 ≥14 398-422 50-53 -0.12 -0.8 100 ≥7.5
52M 1.42-1.44 14.2-14.4 ≥1114 ≥14 390-422 49-53 -0.12 -0.8 100 ≥7.5
50M 1.4-1.42 14-14.2 ≥1114 ≥14 374-406 47-51 -0.12 -0.8 100 ≥7.5
48M 1.37-1.4 13.7-14 ≥1114 ≥14 366-390 46-49 -0.12 -0.8 100 ≥7.5
45M 1.32-1.37 13.2-13.7 ≥1114 ≥14 342-366 43-46 -0.12 -0.8 100 ≥7.5
42M 1.28-1.32 12.8-13.2 ≥1114 ≥14 318-342 40-43 -0.12 -0.8 100 ≥7.5
54H ≥1.44 ≥14.4 ≥1353 ≥17 398-422 50-53 -0.12 -0.7 120 ≥7.5
52H 1.42-1.44 14.2-14.4 ≥1353 ≥17 390-422 49-53 -0.12 -0.7 120 ≥7.5
50H 1.4-1.42 14-14.2 ≥1353 ≥17 374-406 47-51 -0.12 -0.7 120 ≥7.5
48H 1.37-1.4 13.7-14 ≥1353 ≥17 366-390 46-49 -0.12 -0.7 120 ≥7.5
45H 1.32-1.37 13.2-13.7 ≥1353 ≥17 342-366 43-46 -0.12 -0.7 120 ≥7.5
42H 1.28-1.32 12.8-13.2 ≥1353 ≥17 318-342 40-43 -0.12 -0.7 120 ≥7.5
40H 1.26-1.28 12.6-12.8 ≥1353 ≥17 302-326 38-41 -0.12 -0.7 120 ≥7.5
52SH 1.42-1.44 14.2-14.4 ≥1592 ≥20 390-422 49-53 -0.12 -0.6 150 ≥7.5
50SH 1.4-1.42 14-14.2 ≥1592 ≥20 374-406 47-51 -0.12 -0.6 150 ≥7.5
48SH 1.37-1.4 13.7-14 ≥1592 ≥20 366-390 46-49 -0.12 -0.6 150 ≥7.5
45SH 1.32-1.37 13.2-13.7 ≥1592 ≥20 342-366 43-46 -0.12 -0.6 150 ≥7.5
42SH 1.28-1.32 12.8-13.2 ≥1592 ≥20 318-342 40-43 -0.12 -0.6 150 ≥7.5
40SH 1.26-1.28 12.6-12.8 ≥1592 ≥20 302-326 38-41 -0.12 -0.6 150 ≥7.5
38SH 1.22-1.26 12.2-12.6 ≥1592 ≥20 287-310 36-39 -0.12 -0.6 150 ≥7.5
35SH 1.17-1.22 11.7-12.2 ≥1592 ≥20 263-287 33-36 -0.12 -0.6 150 ≥7.5
33SH 1.13-1.17 11.3-11.7 ≥1592 ≥20 247-271 31-34 -0.12 -0.6 150 ≥7.5
30SH 1.08-1.13 10.8-11.3 ≥1592 ≥20 223-254 28-32 -0.12 -0.6 150 ≥7.5
48UH 1.36-1.4 13.6-14 ≥1990 ≥25 366-390 46-49 -0.12 -0.6 180 ≥7.5
45UH 1.32-1.37 13.2-13.7 ≥1990 ≥25 342-366 43-46 -0.12 -0.6 180 ≥7.5
42UH 1.28-1.32 12.8-13.2 ≥1990 ≥25 318-342 40-43 -0.12 -0.6 180 ≥7.5
40UH 1.26-1.28 12.6-12.8 ≥1990 ≥25 302-326 38-41 -0.12 -0.6 180 ≥7.5
38UH 1.22-1.26 12.2-12.6 ≥1990 ≥25 287-310 36-39 -0.12 -0.6 180 ≥7.5
35UH 1.17-1.22 11.7-12.2 ≥1990 ≥25 263-287 33-36 -0.12 -0.6 180 ≥7.5
33UH 1.13-1.17 11.3-11.7 ≥1990 ≥25 247-271 31-34 -0.12 -0.6 180 ≥7.5
30UH 1.08-1.13 10.8-11.3 ≥1990 ≥25 223-255 28-32 -0.12 -0.51 180 ≥7.5
28UH 1.02-1.08 10.2-10.8 ≥1990 ≥25 207-231 26-29 -0.12 -0.51 180 ≥7.5
42EH 1.28-1.32 12.8-13.2 ≥2388 ≥30 318-342 40-43 -0.12 -0.5 200 ≥7.5
40EH 1.25-1.28 12.5-12.8 ≥2388 ≥30 302-326 38-41 -0.12 -0.5 200 ≥7.5
38EH 1.22-1.26 12.2-12.6 ≥2388 ≥30 287-310 36-39 -0.12 -0.5 200 ≥7.5
35EH 1.17-1.22 11.7-12.2 ≥2388 ≥30 263-287 33-36 -0.12 -0.5 200 ≥7.5
33EH 1.13-1.17 11.3-11.7 ≥2388 ≥30 247-271 31-34 -0.12 -0.5 200 ≥7.5
30EH 1.08-1.13 10.8-11.3 ≥2388 ≥30 223-255 28-32 -0.12 -0.51 200 ≥7.5
28EH 1.02-1.08 10.2-10.8 ≥2388 ≥30 207-231 26-29 -0.12 -0.51 200 ≥7.5
40AH 1.25-1.28 12.5-12.8 ≥2786 ≥35 302-326 38-41 -0.12 -0.51 220 ≥7.5
38AH 1.22-1.26 12.2-12.6 ≥2786 ≥35 287-310 36-39 -0.12 -0.51 220 ≥7.5
35AH 1.17-1.22 11.7-12.2 ≥2786 ≥35 263-287 33-36 -0.12 -0.51 220 ≥7.5
33AH 1.13-1.17 11.3-11.7 ≥2786 ≥35 247-271 31-34 -0.12 -0.51 220 ≥7.5
30AH 1.08-1.13 10.8-11.3 ≥2786 ≥35 223-255 28-32 -0.12 -0.51 220 ≥7.5
28AH 1.02-1.08 10.2-10.8 ≥2786 ≥35 199-231 25-29 -0.12 -0.51 220 ≥7.5

Industrial Super Strong Magnet with Working Temp 80-230 Centigrade and Custom Options 0
