80-230 Centigrade NdFeB Magnet for Traction Motor Automotive EPS Motor Air Conditioner

  • 80-230 Centigrade NdFeB Magnet for Traction Motor Automotive EPS Motor Air Conditioner
  • 80-230 Centigrade NdFeB Magnet for Traction Motor Automotive EPS Motor Air Conditioner
Place of Origin CHINA
Brand Name JN
Certification ISO9001
Model Number JN-ND-1
Minimum Order Quantity 1000PCS
Price Negotiable
Packaging Details By Sea Pallet /By Air Carton / By Express Packaging
Delivery Time 21 Days
Payment Terms L/C,T/T
Supply Ability 1 000K PCS/Month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Application Traction Motor Automotive EPS Motor Air Conditioner Max Working Temp 230ºC
Grand Available N35-N52 Type Of Magnet NdFeB Magnets
Process Sintering Coating Nickel Epoxy Zn Ni
Tolerance +/- 0.05 Mm Raw Material NdFeB Rare Earth Materials
Category Neodymium Magnets
Highlight

ndfeb magnet for traction motor

,

motor ndfeb magnet

,

motor ndfeb magnets
Leave a Message
Product Description

80-230 Centigrade NdFeB Magnet for Traction Motor Automotive EPS Motor Air Conditioner

Product Description:

NdFeB Magnet: A Powerful and Versatile Rare Earth Magnet

The NdFeB Magnet, also known as the Neodymium Rare Earth Magnet, is a type of permanent magnet made from a combination of neodymium, iron, and boron. This powerful magnet is known for its high magnetic strength, making it a popular choice in various industries. In this product overview, we will discuss the key features and applications of the NdFeB Magnet.

Tolerance and Raw Material

The NdFeB Magnet is manufactured with a tolerance of +/- 0.05mm, ensuring precision and accuracy in its dimensions. This level of tolerance is essential in applications where minimal variations can affect the overall performance of the product. The raw materials used in the production of NdFeB Magnets are neodymium, iron, and boron, which are all rare earth materials. These materials are known for their exceptional magnetic properties, making the NdFeB Magnet one of the strongest permanent magnets available.

Applications

The versatility of the NdFeB Magnet makes it suitable for a wide range of applications. Its high magnetic strength and tolerance make it ideal for use in traction motors, such as those in electric vehicles. It is also commonly used in automotive EPS motors for power steering, as well as in air conditioners for efficient cooling. Its strong magnetic force also makes it an excellent choice for use in generators, speakers, and magnetic separators.

Working Temperature and Grade Available

The NdFeB Magnet has a high working temperature range of 80-230 degrees Celsius, making it suitable for use in various environments. It can withstand high temperatures without any significant loss in its magnetic strength, making it a reliable choice for applications that require consistent performance. The NdFeB Magnet is available in various grades, ranging from N35 to N52. The higher the grade, the stronger the magnetic force of the magnet.

Conclusion

In summary, the NdFeB Magnet is a powerful and versatile product that offers high magnetic strength, precision, and a wide range of applications. Its unique combination of neodymium, iron, and boron makes it one of the strongest permanent magnets available. With a high working temperature range and various grades available, the NdFeB Magnet is a reliable and efficient choice for industries that require strong and precise magnetic properties. Contact us now to learn more about our NdFeB Magnet and how it can benefit your business.

Technical Parameters:

Process Type Of Magnet Tolerance Working Temp Coating Size Max Working Temp Grade Available Application Raw Material
Sintering NdFeB Magnets +/- 0.05 mm 80-230°C Nickel Epoxy Zn Ni Custom 230°C N35-N52 Traction Motor, Automotive EPS Motor, Air Conditioner NdFeB Rare Earth Materials

Magnetic Properties
Grade Remanence Intrinsic Coercivity Max Magnetic Energy Product Temperature Coefficient Max Working Temperture Density
Br Hcj (BH)max α Br β Hcj Tw ρ
T kGs kA/m kOe KJ/m3 MGOe %/℃ %/℃ ℃ g/cm3
N55 ≥1.45 ≥14.5 ≥955 ≥12 406-437 51-55 -0.12 -0.8 80 ≥7.5
N54 ≥1.44 ≥14.4 ≥955 ≥12 398-437 50-55 -0.12 -0.8 80 ≥7.5
N52 1.42-1.44 14.2-14.4 ≥955 ≥12 390-422 49-53 -0.12 -0.8 80 ≥7.5
N50 1.4-1.42 14-14.2 ≥955 ≥12 374-406 47-51 -0.12 -0.8 80 ≥7.5
N48 1.37-1.4 13.7-14 ≥955 ≥12 366-390 46-49 -0.12 -0.8 80 ≥7.5
N45 1.32-1.37 13.2-13.7 ≥955 ≥12 342-366 43-46 -0.12 -0.8 80 ≥7.5
54M ≥1.44 ≥14.4 ≥1114 ≥14 398-422 50-53 -0.12 -0.8 100 ≥7.5
52M 1.42-1.44 14.2-14.4 ≥1114 ≥14 390-422 49-53 -0.12 -0.8 100 ≥7.5
50M 1.4-1.42 14-14.2 ≥1114 ≥14 374-406 47-51 -0.12 -0.8 100 ≥7.5
48M 1.37-1.4 13.7-14 ≥1114 ≥14 366-390 46-49 -0.12 -0.8 100 ≥7.5
45M 1.32-1.37 13.2-13.7 ≥1114 ≥14 342-366 43-46 -0.12 -0.8 100 ≥7.5
42M 1.28-1.32 12.8-13.2 ≥1114 ≥14 318-342 40-43 -0.12 -0.8 100 ≥7.5
54H ≥1.44 ≥14.4 ≥1353 ≥17 398-422 50-53 -0.12 -0.7 120 ≥7.5
52H 1.42-1.44 14.2-14.4 ≥1353 ≥17 390-422 49-53 -0.12 -0.7 120 ≥7.5
50H 1.4-1.42 14-14.2 ≥1353 ≥17 374-406 47-51 -0.12 -0.7 120 ≥7.5
48H 1.37-1.4 13.7-14 ≥1353 ≥17 366-390 46-49 -0.12 -0.7 120 ≥7.5
45H 1.32-1.37 13.2-13.7 ≥1353 ≥17 342-366 43-46 -0.12 -0.7 120 ≥7.5
42H 1.28-1.32 12.8-13.2 ≥1353 ≥17 318-342 40-43 -0.12 -0.7 120 ≥7.5
40H 1.26-1.28 12.6-12.8 ≥1353 ≥17 302-326 38-41 -0.12 -0.7 120 ≥7.5
52SH 1.42-1.44 14.2-14.4 ≥1592 ≥20 390-422 49-53 -0.12 -0.6 150 ≥7.5
50SH 1.4-1.42 14-14.2 ≥1592 ≥20 374-406 47-51 -0.12 -0.6 150 ≥7.5
48SH 1.37-1.4 13.7-14 ≥1592 ≥20 366-390 46-49 -0.12 -0.6 150 ≥7.5
45SH 1.32-1.37 13.2-13.7 ≥1592 ≥20 342-366 43-46 -0.12 -0.6 150 ≥7.5
42SH 1.28-1.32 12.8-13.2 ≥1592 ≥20 318-342 40-43 -0.12 -0.6 150 ≥7.5
40SH 1.26-1.28 12.6-12.8 ≥1592 ≥20 302-326 38-41 -0.12 -0.6 150 ≥7.5
38SH 1.22-1.26 12.2-12.6 ≥1592 ≥20 287-310 36-39 -0.12 -0.6 150 ≥7.5
35SH 1.17-1.22 11.7-12.2 ≥1592 ≥20 263-287 33-36 -0.12 -0.6 150 ≥7.5
33SH 1.13-1.17 11.3-11.7 ≥1592 ≥20 247-271 31-34 -0.12 -0.6 150 ≥7.5
30SH 1.08-1.13 10.8-11.3 ≥1592 ≥20 223-254 28-32 -0.12 -0.6 150 ≥7.5
48UH 1.36-1.4 13.6-14 ≥1990 ≥25 366-390 46-49 -0.12 -0.6 180 ≥7.5
45UH 1.32-1.37 13.2-13.7 ≥1990 ≥25 342-366 43-46 -0.12 -0.6 180 ≥7.5
42UH 1.28-1.32 12.8-13.2 ≥1990 ≥25 318-342 40-43 -0.12 -0.6 180 ≥7.5
40UH 1.26-1.28 12.6-12.8 ≥1990 ≥25 302-326 38-41 -0.12 -0.6 180 ≥7.5
38UH 1.22-1.26 12.2-12.6 ≥1990 ≥25 287-310 36-39 -0.12 -0.6 180 ≥7.5
35UH 1.17-1.22 11.7-12.2 ≥1990 ≥25 263-287 33-36 -0.12 -0.6 180 ≥7.5
33UH 1.13-1.17 11.3-11.7 ≥1990 ≥25 247-271 31-34 -0.12 -0.6 180 ≥7.5
30UH 1.08-1.13 10.8-11.3 ≥1990 ≥25 223-255 28-32 -0.12 -0.51 180 ≥7.5
28UH 1.02-1.08 10.2-10.8 ≥1990 ≥25 207-231 26-29 -0.12 -0.51 180 ≥7.5
42EH 1.28-1.32 12.8-13.2 ≥2388 ≥30 318-342 40-43 -0.12 -0.5 200 ≥7.5
40EH 1.25-1.28 12.5-12.8 ≥2388 ≥30 302-326 38-41 -0.12 -0.5 200 ≥7.5
38EH 1.22-1.26 12.2-12.6 ≥2388 ≥30 287-310 36-39 -0.12 -0.5 200 ≥7.5
35EH 1.17-1.22 11.7-12.2 ≥2388 ≥30 263-287 33-36 -0.12 -0.5 200 ≥7.5
33EH 1.13-1.17 11.3-11.7 ≥2388 ≥30 247-271 31-34 -0.12 -0.5 200 ≥7.5
30EH 1.08-1.13 10.8-11.3 ≥2388 ≥30 223-255 28-32 -0.12 -0.51 200 ≥7.5
28EH 1.02-1.08 10.2-10.8 ≥2388 ≥30 207-231 26-29 -0.12 -0.51 200 ≥7.5
40AH 1.25-1.28 12.5-12.8 ≥2786 ≥35 302-326 38-41 -0.12 -0.51 220 ≥7.5
38AH 1.22-1.26 12.2-12.6 ≥2786 ≥35 287-310 36-39 -0.12 -0.51 220 ≥7.5
35AH 1.17-1.22 11.7-12.2 ≥2786 ≥35 263-287 33-36 -0.12 -0.51 220 ≥7.5
33AH 1.13-1.17 11.3-11.7 ≥2786 ≥35 247-271 31-34 -0.12 -0.51 220 ≥7.5
30AH 1.08-1.13 10.8-11.3 ≥2786 ≥35 223-255 28-32 -0.12 -0.51 220 ≥7.5
28AH 1.02-1.08 10.2-10.8 ≥2786 ≥35 199-231 25-29 -0.12 -0.51 220 ≥7.5

80-230 Centigrade NdFeB Magnet for Traction Motor Automotive EPS Motor Air Conditioner 0



FAQ:

  • Q: What is the brand name of this product?
    A: The brand name is JN.
  • Q: What is the model number of this product?
    A: The model number is JN-ND-1.
  • Q: Where is this product manufactured?
    A: This product is manufactured in China.
  • Q: Does this product have any certifications?
    A: Yes, this product is certified with ISO9001.
  • Q: What is the minimum order quantity for this product?
    A: The minimum order quantity is 1000PCS.
  • Q: Is the price negotiable for this product?
    A: Yes, the price for this product is negotiable.
  • Q: How is this product packaged?
    A: This product can be packaged either by Sea Pallet, Air Carton, or Express Packaging.
  • Q: How long does it take for this product to be delivered?
    A: The delivery time for this product is 21 days.
  • Q: What are the payment terms for this product?
    A: The payment terms for this product are L/C and T/T.
  • Q: What is the supply ability for this product?
    A: The supply ability for this product is 1,000K PCS per month.
