Curie Temperature 700-800°C High Temperature SmCo Magnet For Motors
| Place of Origin | CHINA |
|---|---|
| Brand Name | JN |
| Certification | ISO9001 |
| Model Number | JN-CO-2 |
| Minimum Order Quantity | 500PCS |
| Price | Negotiable |
| Packaging Details | By Sea Pallet /By Air Carton / By Express Packaging |
| Delivery Time | 25 Days |
| Payment Terms | L/C,T/T |
| Supply Ability | 500K PCS/Month |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Magnetic Properties | High Magnetic Energy Product, High Coercive Force, High Remanence | Color | Brown, Black |
|---|---|---|---|
| Tolerance | 0.1mm | Curie Temperature | 700-800°C |
| Property | Isotropic And Anisotropic Is Avaible | Mechanical Properties | Brittle, Hard, Difficult To Machine |
| Magnetization | Multipolar Or So | Demagnetization Resistance | Excellent |
| Highlight | SmCo Magnet for Motors,Isotropic SmCo Magnet,Anisotropic Motor Magnet |
||
Product Description
Curie Temperature 700-800°C High Temperature SmCo Magnet for Motors
Product Description:
SmCo Rare Earth Magnet - The Ultimate Choice for High-Performance Applications
SmCo Magnet, also known as Cobalt SmCo Magnet, is a powerful and versatile rare earth magnet that offers exceptional magnetic properties. It is composed of samarium, cobalt, and iron, making it incredibly strong and durable. With its high magnetic energy product, high coercive force, and high remanence, SmCo Magnet is the perfect solution for a wide range of applications.
Applications
SmCo Magnet is widely used in various industries, including motors, sensors, magnetic couplings, magnetic separators, and more. Its superior magnetic properties make it an ideal choice for high-performance applications that require strong and reliable magnets.
Demagnetization Resistance
One of the key features of SmCo Magnet is its excellent demagnetization resistance. This means that the magnet will maintain its strength and magnetic properties even under extreme conditions, making it suitable for long-term use.
Property
SmCo Magnet is available in both isotropic and anisotropic forms, giving you the flexibility to choose the right magnet for your specific needs. Isotropic SmCo Magnet has the same magnetic properties in all directions, while anisotropic SmCo Magnet has a preferred direction of magnetization, providing even higher magnetic strength.
Magnetic Properties
SmCo Magnet is known for its exceptional magnetic properties. It has a high magnetic energy product, which is the measure of the maximum amount of magnetic energy that a magnet can store. It also has a high coercive force, which is the resistance of a magnet to demagnetization, and a high remanence, which is the magnetic flux density remaining in a magnet after it has been magnetized.
Color
SmCo Magnet is available in two primary colors – brown and black. These colors are achieved through the use of different surface treatments and coatings, making the magnet not only powerful but also aesthetically appealing.
Types
SmCo Magnet comes in various shapes and sizes to suit different applications. The most common types are block SmCo Magnet and disc SmCo Magnet, but it is also available in other shapes like ring, arc, and more.
With its exceptional magnetic properties, demagnetization resistance, and availability in different forms and colors, SmCo Magnet is the ultimate choice for high-performance applications. Invest in SmCo Magnet today and experience the power and versatility of this rare earth magnet.
Features:
- Product Name: SmCo Magnet
- Shape:
- Disc
- Cylinder
- Block
- Ring
- Arc
- Segment
- Etc.
- Mechanical Properties:
- Brittle
- Hard
- Difficult To Machine
- Advantages:
- High Temperature Stability
- High Magnetic Strength
- Corrosion Resistance
- Tolerance: 0.1mm
- Demagnetization Resistance: Excellent
- Permanent Magnet SmCo
- Block SmCo Magnet
- Samarium Cobalt Magnet
Technical Parameters:
| Property | Technical Specifications |
|---|---|
| Product Name | Rare Earth Cobalt Magnet (SmCo Magnet) |
| Magnetization | Multipolar Or So |
| Color | Brown, Black |
| Demagnetization Resistance | Excellent |
| Applications | Motors, Sensors, Magnetic Couplings, Magnetic Separators, Etc. |
| Mechanical Properties | Brittle, Hard, Difficult To Machine |
| Tolerance | 0.1mm |
| Magnetic Properties | High Magnetic Energy Product, High Coercive Force, High Remanence |
| Shape | Disc, Cylinder, Block, Ring, Arc, Segment, Etc. |
| Advantages | High Temperature Stability, High Magnetic Strength, Corrosion Resistance |
| Property | Isotropic And Anisotropic Is Avaible |
| Grade | Residual Induction | Coercive Force | Intrinsic Coercive Force |
Max. Energy Product |
Max. Working Temperature | ||||||
| Br | Hcb | Hcj | (BH)max | Tw | |||||||
| kGs | T | kOe | KA/m | kOe | KA/m | MGOe | KJ/m³ | ℃ | |||
| SmCo5 | SC16 | 8.1-8.5 | 0.81-0.85 | 7.8-8.3 | 620-660 | 15-23 | 1194-1830 | 14-16 | 110-127 | 250 | |
| SC18 | 8.5-9.0 | 0.85-0.90 | 8.3-8.8 | 660-700 | 15-23 | 1194-1830 | 16-18 | 127-143 | 250 | ||
| SC20 | 9.0-9.4 | 0.90-0.94 | 8.5-9.1 | 676-725 | 15-23 | 1194-1830 | 19-21 | 150-167 | 250 | ||
| SC22 | 9.2-9.6 | 0.92-0.96 | 8.9-9.4 | 710-748 | 15-23 | 1194-1830 | 20-22 | 160-175 | 250 | ||
| SC24 | 9.6-10.0 | 0.96- 1.00 | 9.2-9.7 | 730-770 | 15-23 | 1194-1830 | 22-24 | 175-190 | 250 | ||
| Sm2Co17 | SCS22 | 9.3-9.7 | 0.93-0.97 | 8.5-9.3 | 676-740 | >18 | >1433 | 20-23 | 160-183 | 350 | |
| SCS24 | 9.5-10.2 | 0.95- 1.02 | 8.7-9.6 | 692-764 | >18 | >1433 | 22-24 | 175-191 | 350 | ||
| SCS24H | 9.5-10.2 | 0.95- 1.02 | 8.7-9.6 | 692-764 | >25 | >1990 | 22-24 | 175-191 | 350 | ||
| SCS26M | 10.2-10.5 | 1.02- 1.05 | 8.5-9.8 | 676-780 | 12-18 | 955-1433 | 24-26 | 191-207 | 350 | ||
| SCS26 | 10.2-10.5 | 1.02- 1.05 | 9.4-10.0 | 748-796 | >18 | >1433 | 24-26 | 191-207 | 350 | ||
| SCS26H | 10.2-10.5 | 1.02- 1.05 | 9.4-10.0 | 748-796 | >25 | >1990 | 24-26 | 191-207 | 350 | ||
| SCS28M | 10.3-10.8 | 1.03- 1.08 | 8.5-10.0 | 676-796 | 12-18 | 955-1433 | 26-28 | 207-223 | 350 | ||
| SCS28 | 10.3-10.8 | 1.03- 1.08 | 9.5-10.2 | 796-812 | >18 | >1433 | 26-28 | 207-223 | 350 | ||
| SCS28H | 10.3-10.8 | 1.03- 1.08 | 9.5-10.2 | 796-812 | >25 | >1990 | 26-28 | 207-223 | 350 | ||
| SCS30M | 10.8-11.0 | 1.08- 1.10 | 8.5-10.5 | 676-835 | 12-18 | 955-1433 | 28-30 | 223-239 | 350 | ||
| SCS30 | 10.8-11.0 | 1.08- 1.10 | 9.9-10.5 | 788-835 | >18 | >1433 | 28-30 | 223-239 | 350 | ||
| SCS30H | 10.8-11.0 | 1.08- 1.10 | 9.9-10.5 | 788-835 | >25 | >1990 | 28-30 | 223-239 | 350 | ||
| SCS32M | 11.0-11.3 | 1.10-1.13 | 8.5-10.7 | 676-852 | 12-18 | 955-1433 | 29-32 | 231-255 | 350 | ||
| SCS32 | 11.0-11.3 | 1.10-1.13 | 10.2-10.8 | 812-860 | >18 | >1433 | 29-32 | 231-255 | 350 | ||
| SCS32H | 11.0-11.3 | 1.10-1.13 | 10.2-10.8 | 812-860 | >25 | >1990 | 29-32 | 231-255 | 350 | ||
| SCS35 | 11.6-12.0 | 1.16-1.20 | 10.9-11.4 | 868-908 | >18 | >1433 | 32-35 | 255-278 | 350 | ||
| Low Temp Coeff Sm2Co17 | SCL18LT | 8.4-8.9 | 0.84-0.89 | 7.9-8.4 | 629-668 | >18 | >1433 | 17-19 | 135-151 | 350 | |
| SCL20LT | 8.9-9.4 | 0.89-0.94 | 8.3-8.9 | 660-708 | >18 | >1433 | 19-21 | 151-167 | 350 | ||
| SCL22LT | 9.4-9.8 | 0.94-0.98 | 8.7-9.3 | 692-740 | >18 | >1433 | 21-23 | 167-183 | 350 | ||
| High Temp Resistance Sm2Co17 | SCG24 | 9.9-10.4 | 0.99- 1.04 | 9.3-9.9 | 740-788 | >23 | >1830 | 23-25 | 183-199 | 400 | |
| SCG22 | 9.4-9.9 | 0.94-0.99 | 8.8-9.4 | 700-748 | >23 | >1830 | 21-23 | 167-183 | 450 | ||
| SCG20 | 8.9-9.4 | 0.89-0.94 | 8.3-8.9 | 660-708 | >23 | >1830 | 19-21 | 151-167 | 500 | ||
Applications:
SmCo Magnet - High Temperature Permanent Magnet
SmCo Magnet, also known as samarium cobalt magnet, is a type of permanent magnet with high temperature stability, high magnetic strength, and corrosion resistance. It is made of an alloy of samarium and cobalt, along with small amounts of other rare earth elements, such as iron, copper, and zirconium.
JN-CO-2 SmCo Magnet, produced by JN company in China, is a high quality and reliable product. It is certified with ISO9001 and can be customized according to customers' needs. The minimum order quantity is 500 pieces and the price is negotiable. It can be delivered within 25 days and the supply ability is 500,000 pieces per month.
One of the main advantages of SmCo Magnet is its high temperature stability. It can maintain its magnetic properties at temperatures up to 700-800°C, making it suitable for use in high temperature environments. This makes it ideal for applications in industries such as aerospace, automotive, and energy.
Another advantage is its high magnetic strength. SmCo Magnet has a very strong magnetic field, which allows it to be used in applications where a strong magnetic force is required, such as in motors, sensors, and magnetic couplings. Its strong magnetic force also makes it useful in magnetic separators, where it can effectively separate ferrous materials from non-ferrous materials.
However, SmCo Magnet also has some mechanical properties that need to be considered. It is a brittle and hard material, which makes it difficult to machine. Therefore, it is recommended to use diamond tools for cutting and shaping SmCo Magnet.
JN-CO-2 SmCo Magnet is available in both isotropic and anisotropic forms. Isotropic SmCo Magnet has the same magnetic properties in all directions, while anisotropic SmCo Magnet has a preferred direction of magnetization, giving it even higher magnetic strength. This allows for more flexibility in its applications.
With its unique properties, SmCo Magnet has a wide range of applications. It can be found in motors, generators, sensors, magnetic couplings, magnetic separators, and many other fields. Its high temperature stability and strong magnetic force make it a popular choice in industries where high performance and reliability are required.
Product Specifications:
- Brand Name: JN
- Model Number: JN-CO-2
- Place of Origin: China
- Certification: ISO9001
- Minimum Order Quantity: 500 pieces
- Price: Negotiable
- Packaging Details: By Sea Pallet/By Air Carton/By Express Packaging
- Delivery Time: 25 Days
- Payment Terms: L/C, T/T
- Supply Ability: 500,000 pieces per month
Overall, SmCo Magnet is a reliable and high-performance product that can provide solutions for various industries and applications. With its high temperature stability, strong magnetic force, and corrosion resistance, it is an essential component in modern technology and will continue to be in demand in the future.
Customization:
SmCo Magnet - JN
Brand Name: JN
Model Number: JN-CO-2
Place of Origin: CHINA
Certification: ISO9001
Minimum Order Quantity: 500PCS
Price: Negotiable
Packaging Details: By Sea Pallet /By Air Carton / By Express Packaging
Delivery Time: 25 Days
Payment Terms: L/C,T/T
Supply Ability: 500K PCS/Month
Advantages: High Temperature Stability, High Magnetic Strength, Corrosion Resistance
Applications: Motors, Sensors, Magnetic Couplings, Magnetic Separators, Etc.
Mechanical Properties: Brittle, Hard, Difficult To Machine
Curie Temperature: 700-800°C
Demagnetization Resistance: Excellent
Customized Service for SmCo Magnet
At JN, we offer customized services for our high-quality SmCo magnets. Our SmCo magnets are available in various shapes, including ring, bar, and cobalt SmCo magnets. Our customized services cater to the specific needs of our customers and ensure that they receive the highest quality products that meet their requirements.
Why Choose JN for Customized SmCo Magnets?
- ISO9001 certified manufacturer
- Minimum order quantity of 500PCS
- Competitive and negotiable pricing
- Fast and reliable delivery time of 25 days
- Flexible payment terms of L/C and T/T
- Supply ability of up to 500K PCS per month
- High temperature stability, high magnetic strength, and corrosion resistance
- Wide range of applications including motors, sensors, magnetic couplings, and separators
- Excellent mechanical properties, but can be brittle and difficult to machine
- Curie temperature of 700-800°C and excellent demagnetization resistance
Customization Options
Our customization options for SmCo magnets include:
- Shape: Our SmCo magnets are available in ring, bar, and cobalt shapes.
- Size: We offer a variety of sizes to choose from, depending on your specific needs.
- Coating: Our SmCo magnets can be coated with various materials such as nickel, zinc, or epoxy to enhance their durability and resistance to corrosion.
- Grade: We offer different grades of SmCo magnets, such as SmCo5 and Sm2Co17, to provide varying levels of magnetic strength.
- Customized Markings: We can add custom markings, labels, or logos on the magnets to meet your branding needs.
At JN, we are committed to providing high-quality SmCo magnets with personalized solutions to meet the specific requirements of our customers. Contact us today to learn more about our customized services for SmCo magnets.
FAQ:
- Q: What is the brand name of this product?
- A: The brand name of this product is JN.
- Q: What is the model number of this product?
- A: The model number of this product is JN-CO-2.
- Q: Where is this product made?
- A: This product is made in China.
- Q: Does this product have any certifications?
- A: Yes, this product is ISO9001 certified.
- Q: What is the minimum order quantity for this product?
- A: The minimum order quantity for this product is 500PCS.
- Q: Can the price of this product be negotiated?
- A: Yes, the price of this product is negotiable.
- Q: How is this product packaged?
- A: This product can be packaged by sea pallet, air carton, or express packaging.
- Q: How long is the delivery time for this product?
- A: The delivery time for this product is 25 days.
- Q: What are the payment terms for this product?
- A: The payment terms for this product are L/C and T/T.
- Q: What is the supply ability for this product?
- A: The supply ability for this product is 500K PCS per month.
