Block SmCo Magnet With High Coercive Force And Curie Temperature 700C - 800C

Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProperty | Isotropic And Anisotropic Is Avaible | Color | Brown, Black |
---|---|---|---|
Mechanical Properties | Brittle, Hard, Difficult To Machine | Magnetic Properties | High Magnetic Energy Product, High Coercive Force, High Remanence |
Curie Temperature | 700-800°C | Tolerance | 0.1mm |
Magnetization | Multipolar Or So | Demagnetization Resistance | Excellent |
Highlight | SmCo Magnet 700C,SmCo Magnet 800C,samarium cobalt 0.1mm Tolerance |
Block SmCo Magnet with High Coercive Force and Curie Temperature 700-800°C
Product Description:
SmCo Magnet, also known as Samarium Cobalt Magnet, is a type of rare earth magnet that is known for its excellent demagnetization resistance and high magnetic properties. It is widely used in various industries due to its unique characteristics and exceptional performance.
SmCo Magnet has excellent demagnetization resistance, which means it can maintain its magnetic properties even in high temperatures or strong magnetic fields. This makes it suitable for applications where other magnets may fail, such as in motors, sensors, and speakers.
SmCo Magnet has high magnetic energy product, which is a measure of the strength of a magnet. It also has high coercive force, which refers to its ability to resist demagnetization, and high remanence, which indicates the strength of its residual magnetization. These properties make SmCo Magnet one of the strongest permanent magnets available.
SmCo Magnet can be magnetized in a multipolar or so configuration, which means it can have multiple poles on its surface. This allows for more precise and efficient use of the magnet in various applications.
SmCo Magnet is known to be brittle, hard, and difficult to machine. This is due to its composition of rare earth elements, making it a challenging material to work with. However, its mechanical properties do not affect its magnetic performance, making it a top choice for industrial and commercial use.
SmCo Magnet is available in various shapes, including disc, cylinder, block, ring, arc, segment, etc. This makes it versatile and adaptable to different applications, from small electronic devices to large industrial machines.
One of the most popular shapes of SmCo Magnet is the block shape. It is widely used in motors, sensors, and other high-performance applications due to its strong magnetic properties and excellent demagnetization resistance.
SmCo Magnet is also known for its high-temperature resistance, making it suitable for applications that require magnets to operate in extreme heat. It can withstand temperatures up to 350°C, making it a preferred choice for use in aerospace, military, and automotive industries.
In summary, SmCo Magnet is a high-performance magnet with exceptional demagnetization resistance, high magnetic properties, and versatile shapes. Its unique composition and characteristics make it an ideal choice for various applications, particularly in high-temperature environments.
Features:
- Product Name: SmCo Magnet
- Advantages:
- High Temperature Stability
- High Magnetic Strength
- Corrosion Resistance
- Magnetic Properties:
- High Magnetic Energy Product
- High Coercive Force
- High Remanence
- Curie Temperature: 700-800°C
- Property: Isotropic And Anisotropic Is Avaible
- Mechanical Properties:
- Brittle
- Hard
- Difficult To Machine
- Bar SmCo Magnet
- Block SmCo Magnet
- Cobalt SmCo Magnet
Technical Parameters:
Product Name | Cobalt SmCo Magnet |
---|---|
Color | Brown, Black |
Shape | Disc, Cylinder, Block, Ring, Arc, Segment, Etc. |
Tolerance | 0.1mm |
Mechanical Properties | Brittle, Hard, Difficult To Machine |
Property | Isotropic And Anisotropic Is Available |
Magnetization | Multipolar Or So |
Magnetic Properties | High Magnetic Energy Product, High Coercive Force, High Remanence |
Curie Temperature | 700-800°C |
Applications | motors, sensors, magnetic couplings, magnetic separators, etc. |
Demagnetization Resistance | Excellent |
Product Name | Disc SmCo Magnet |
---|---|
Color | Brown, Black |
Shape | Disc |
Tolerance | 0.1mm |
Mechanical Properties | Brittle, Hard, Difficult To Machine |
Property | Isotropic And Anisotropic Is Available |
Magnetization | Multipolar Or So |
Magnetic Properties | High Magnetic Energy Product, High Coercive Force, High Remanence |
Curie Temperature | 700-800°C |
Applications | motors, sensors, magnetic couplings, magnetic separators, etc. |
Demagnetization Resistance | Excellent |
Product Name | Samarium Cobalt Magnet |
---|---|
Color | Brown, Black |
Shape | Disc, Cylinder, Block, Ring, Arc, Segment, Etc. |
Tolerance | 0.1mm |
Mechanical Properties | Brittle, Hard, Difficult To Machine |
Property | Isotropic And Anisotropic Is Available |
Magnetization | Multipolar Or So |
Magnetic Properties | High Magnetic Energy Product, High Coercive Force, High Remanence |
Curie Temperature | 700-800°C |
Applications | motors, sensors, magnetic couplings, magnetic separators, etc. |
Demagnetization Resistance | Excellent |
Grade | Residual Induction | Coercive Force | Intrinsic Coercive Force |
Max. Energy Product |
Max. Working Temperature | ||||||
Br | Hcb | Hcj | (BH)max | Tw | |||||||
kGs | T | kOe | KA/m | kOe | KA/m | MGOe | KJ/m³ | ℃ | |||
SmCo5 | SC16 | 8.1-8.5 | 0.81-0.85 | 7.8-8.3 | 620-660 | 15-23 | 1194-1830 | 14-16 | 110-127 | 250 | |
SC18 | 8.5-9.0 | 0.85-0.90 | 8.3-8.8 | 660-700 | 15-23 | 1194-1830 | 16-18 | 127-143 | 250 | ||
SC20 | 9.0-9.4 | 0.90-0.94 | 8.5-9.1 | 676-725 | 15-23 | 1194-1830 | 19-21 | 150-167 | 250 | ||
SC22 | 9.2-9.6 | 0.92-0.96 | 8.9-9.4 | 710-748 | 15-23 | 1194-1830 | 20-22 | 160-175 | 250 | ||
SC24 | 9.6-10.0 | 0.96- 1.00 | 9.2-9.7 | 730-770 | 15-23 | 1194-1830 | 22-24 | 175-190 | 250 | ||
Sm2Co17 | SCS22 | 9.3-9.7 | 0.93-0.97 | 8.5-9.3 | 676-740 | >18 | >1433 | 20-23 | 160-183 | 350 | |
SCS24 | 9.5-10.2 | 0.95- 1.02 | 8.7-9.6 | 692-764 | >18 | >1433 | 22-24 | 175-191 | 350 | ||
SCS24H | 9.5-10.2 | 0.95- 1.02 | 8.7-9.6 | 692-764 | >25 | >1990 | 22-24 | 175-191 | 350 | ||
SCS26M | 10.2-10.5 | 1.02- 1.05 | 8.5-9.8 | 676-780 | 12-18 | 955-1433 | 24-26 | 191-207 | 350 | ||
SCS26 | 10.2-10.5 | 1.02- 1.05 | 9.4-10.0 | 748-796 | >18 | >1433 | 24-26 | 191-207 | 350 | ||
SCS26H | 10.2-10.5 | 1.02- 1.05 | 9.4-10.0 | 748-796 | >25 | >1990 | 24-26 | 191-207 | 350 | ||
SCS28M | 10.3-10.8 | 1.03- 1.08 | 8.5-10.0 | 676-796 | 12-18 | 955-1433 | 26-28 | 207-223 | 350 | ||
SCS28 | 10.3-10.8 | 1.03- 1.08 | 9.5-10.2 | 796-812 | >18 | >1433 | 26-28 | 207-223 | 350 | ||
SCS28H | 10.3-10.8 | 1.03- 1.08 | 9.5-10.2 | 796-812 | >25 | >1990 | 26-28 | 207-223 | 350 | ||
SCS30M | 10.8-11.0 | 1.08- 1.10 | 8.5-10.5 | 676-835 | 12-18 | 955-1433 | 28-30 | 223-239 | 350 | ||
SCS30 | 10.8-11.0 | 1.08- 1.10 | 9.9-10.5 | 788-835 | >18 | >1433 | 28-30 | 223-239 | 350 | ||
SCS30H | 10.8-11.0 | 1.08- 1.10 | 9.9-10.5 | 788-835 | >25 | >1990 | 28-30 | 223-239 | 350 | ||
SCS32M | 11.0-11.3 | 1.10-1.13 | 8.5-10.7 | 676-852 | 12-18 | 955-1433 | 29-32 | 231-255 | 350 | ||
SCS32 | 11.0-11.3 | 1.10-1.13 | 10.2-10.8 | 812-860 | >18 | >1433 | 29-32 | 231-255 | 350 | ||
SCS32H | 11.0-11.3 | 1.10-1.13 | 10.2-10.8 | 812-860 | >25 | >1990 | 29-32 | 231-255 | 350 | ||
SCS35 | 11.6-12.0 | 1.16-1.20 | 10.9-11.4 | 868-908 | >18 | >1433 | 32-35 | 255-278 | 350 | ||
Low Temp Coeff Sm2Co17 | SCL18LT | 8.4-8.9 | 0.84-0.89 | 7.9-8.4 | 629-668 | >18 | >1433 | 17-19 | 135-151 | 350 | |
SCL20LT | 8.9-9.4 | 0.89-0.94 | 8.3-8.9 | 660-708 | >18 | >1433 | 19-21 | 151-167 | 350 | ||
SCL22LT | 9.4-9.8 | 0.94-0.98 | 8.7-9.3 | 692-740 | >18 | >1433 | 21-23 | 167-183 | 350 | ||
High Temp Resistance Sm2Co17 | SCG24 | 9.9-10.4 | 0.99- 1.04 | 9.3-9.9 | 740-788 | >23 | >1830 | 23-25 | 183-199 | 400 | |
SCG22 | 9.4-9.9 | 0.94-0.99 | 8.8-9.4 | 700-748 | >23 | >1830 | 21-23 | 167-183 | 450 | ||
SCG20 | 8.9-9.4 | 0.89-0.94 | 8.3-8.9 | 660-708 | >23 | >1830 | 19-21 | 151-167 | 500 |
Applications:
Brand Name: JN
Model Number: JN-CO-2
Place of Origin: CHINA
Certification: ISO9001
Minimum Order Quantity: 500PCS
Price: Negotiable
Packaging Details: By Sea Pallet /By Air Carton / By Express Packaging
Delivery Time: 25 Days
Payment Terms: L/C,T/T
Supply Ability: 500K PCS/Month
Color: Brown, Black
Shape: Disc, Cylinder, Block, Ring, Arc, Segment, Etc.
Curie Temperature: 700-800°C
Demagnetization Resistance: Excellent
Advantages: High Temperature Stability, High Magnetic Strength, Corrosion Resistance
Introducing the SmCo Magnet from JN - the perfect solution for high temperature applications. Our block SmCo magnet is a type of permanent magnet SmCo, which stands for Samarium Cobalt. This rare earth cobalt magnet is known for its exceptional magnetic properties and is ideal for use in various industries.
The SmCo magnet is designed to withstand high temperatures, making it the perfect choice for applications in industries such as aerospace, automotive, and military. With a Curie temperature of 700-800°C, our SmCo magnet can maintain its magnetic strength even in extreme heat, making it a reliable choice for high temperature environments.
We offer a variety of shapes for our SmCo magnet, including disc, cylinder, block, ring, arc, and segment. This allows for flexibility in design and usage. Additionally, our magnets are available in brown and black color options, providing versatility in application and aesthetics.
Our SmCo magnet has excellent demagnetization resistance, ensuring its long-term performance and durability. This makes it a cost-effective choice for industries that require strong and reliable magnetic solutions.
With our ISO9001 certification and a minimum order quantity of 500PCS, we guarantee high-quality products and efficient service. Our packaging options also cater to different transportation needs, ensuring your magnets arrive safely and on time. With a supply ability of 500K PCS/month, we can meet your bulk orders and provide timely delivery.
Choose JN for your block SmCo magnet needs and experience the advantages of high temperature stability, high magnetic strength, and corrosion resistance. Contact us today to learn more or place an order.
Customization:
Customized Services for SmCo Magnet
- High Temperature Stability
- High Magnetic Strength
- Corrosion Resistance
- Brittle
- Hard
- Difficult To Machine
- High Temperature SmCo Magnet for Motors
- Disc SmCo Magnet for Sensors
- Ring SmCo Magnet for Magnetic Couplings
- Block SmCo Magnet for Magnetic Separators
- Customized Design for Various Applications
- ISO9001 Certified
- Strong Magnetic Force
- Corrosion Resistant
- Brittle Material
- High Precision Tolerance
- Wide Applications
FAQ:
- Q: What is the brand name of this product?
A: The brand name of this product is JN. - Q: What is the model number of this product?
A: The model number of this product is JN-CO-2. - Q: Where is this product manufactured?
A: This product is manufactured in China. - Q: Does this product have any certification?
A: Yes, this product is ISO9001 certified. - Q: What is the minimum order quantity for this product?
A: The minimum order quantity for this product is 500 pieces. - Q: Is the price of this product negotiable?
A: Yes, the price of this product is negotiable. - Q: How is this product packaged for shipping?
A: This product can be packaged by sea pallet, air carton, or express packaging. - Q: What is the estimated delivery time for this product?
A: The estimated delivery time for this product is 25 days. - Q: What are the accepted payment terms for this product?
A: The accepted payment terms for this product are L/C and T/T. - Q: How many pieces of this product can be supplied per month?
A: This product has a supply ability of 500,000 pieces per month.
